Especificaciones
★Support All Intel / AMD Multi-Core CPU & ATX / BTX Compatible Motherboards.
★Support NVIDIA® SLI™ & ATI CrossFireX™ High Performance Graphic Card
★Fully compatible with Intel ATX 3.1 Specifications, supporting up to 200% power excursion..
★OVP/ OCP / OTP/ SCP / OPP / NLP
★Compact 14cm size.
★ECO Fan control design.
★All Flat Cables.
★105°C Taiwanese Full Capacitor.
Model | Zillion FG Gold 1050W ATX3.1 | |
Wattage | 1050W | |
Efficiency | 20%: 87% ; 50% : 90% ; 100% : 87% (115V Internal Gold) Efficiency | |
Intel Power Design Guide | ATX 12V v3.1, EPS 12V v2.92 Specification. | |
AC Input / Frequency | 100V-240V | 60 / 50Hz , Full Range APFC | |
Fan Size | 120mm FDB Fan | |
Dimension | 140mm(L) x 150mm(W) x 86mm(H) | |
Protection | OVP/ OCP / OTP/ SCP / OPP / NLP | |
Safety | CCC / FCC / cTÜVus / TÜV / CE / UKCA | |
Weight | Around 1.5 KG | |
Cable Spec | ||
20+4Pin | Detachable | 1 (600 mm) |
PCI(6+2)Pin | 3 (700mm) | |
8Pin (4+4Pin) | 2 (750mm+150mm) | |
12+4 Pin PCIe | 1 (700mm) | |
4SATA | 2 (550mm+150mm+150mm+150mm) | |
3Molex+FDD | 2 (550mm+150mm+150mm+150mm) | |
Molex to FDD | 1 (100 mm) | |
