MSI B560M PRO-VDH WIFI Socket LGA1200
$144.990
| GETNET (Tarjetas de crédito, débito y prepago) | $148.615 |
| Transferencia Bancaria | $144.990 |
| FLOW (WebPay Crédito/Débito, 3 cuotas sin interés+ otros) | $151.515 |
Agotado
- Processor:
- Supports 10th Gen Intel Core Processors, 11th Gen Intel Core Processors , Pentium Gold and Celeron Processors
- Processor socket LGA1200
- Chipset: Intel B560 Chipset
- Memory:
-
4x DDR4 memory slots, support up to 128GB
-
Supports 1R 2133/ 2666/ 2933 MHz for 10th Gen Intel CPU (by JEDEC & POR)
-
Supports 1R 2133/ 2666/ 2933/ 3200 MHz for 11th Gen Intel CPU (by JEDEC & POR)
-
Max overclocking frequency:– 1DPC 1R Max speed up to 5066 MHz– 1DPC 2R Max speed up to 4600+ MHz– 2DPC 1R Max speed up to 4266+ MHz– 2DPC 2R Max speed up to 4000+ MHz
-
Supports Dual-Channel mode
-
Supports non-ECC, un-buffered memory
-
Supports Intel Extreme Memory Profile (XMP)
-
- Expansion Slots:
-
1x PCIe x16 slot (From CPU): PCI_E1 (From CPU)– Support up to PCIe 4.0 for 11th Gen Intel CPU– Support up to PCIe 3.0 for 10th Gen Intel CPU
-
2x PCIe 3.0 x1 slots (From B560 chpiset)
-
- Onboard Graphics:
-
1x HDMI 2.0b with HDR port, supports a maximum resolution of 4K 60Hz
-
1x DisplayPort 1.4 port, supports a maximum resolution of 4K 60Hz
-
1x VGA port, supports the maximum resolutions of 2048×1536 @50Hz, 2048×1280 @60Hz and 1920×1200 @60Hz
-
-
Audio:
-
Realtek AL897 Codec: 7.1-Channel High Definition Audio
-
-
Lan: 1x Realtek 8125B 2.5Gbps LAN controller
-
Wireless Lan & Bluetooth: Intel Wi-Fi 6 AX201
-
The Wireless module is pre-installed in the M.2 (Key-E) slot
-
Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz (160MHz) up to 2.4Gbps
-
Supports 802.11 a/ b/ g/ n/ ac/ ax
-
WiFi 6 pre certified
-
Supports Bluetooth 5.1, FIPS, FISMA
-
- Storage:
-
6x SATA 6Gb/s ports (From B560 chipset)
-
2x M.2 slot (Key M)– M2_1 slot– Supports up to PCIe 4.0 x4 for 11th Gen Intel CPU (From CPU)– Supports up to PCIe 3.0 x4 & SATA 6Gb/s for 10th Gen Intel CPU (From B560 chipset)– Supports 2242/ 2260/ 2280/ 22110 storage devices– M2_2 slot (from B560 chipset)– Supports up to PCIe 3.0 x4– Supports 2242/ 2260/ 2280 storage devices– Intel Optane Memory Ready
-
Supports Intel Smart Response Technology for Intel Core processors
-
- USB:
-
Intel B560 Chipset– 2x USB 3.2 Gen 2 10Gbps Type-A ports on the back panel– 4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, and 2 ports are available through the internal USB 3.2 Gen 1 5Gbps connector)– 2x USB 2.0 Type-A ports on the back panel
-
USB Hubs GL850G– 4x USB 2.0 ports are available through the internal USB 2.0 connectors
-
-
BIOS Features:
-
1x 256 Mb flash
-
UEFI AMI BIOS
-
ACPI 6.2, SMBIOS 3.0
-
Multi-language
-
- Internal Connectors:
-
1x 24-pin ATX main power connector
-
1x 8-pin ATX 12V power connector
-
6x SATA 6Gb/s connectors
-
2x M.2 slots (M-Key)
-
1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB Gen 1 ports)
-
2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
-
1x 4-pin CPU fan connector
-
1x 4-pin water-pump fan connector
-
2x 4-pin system fan connectors
-
1x Front panel audio connector
-
2x System panel connectors
-
1x Chassis Intrusion connector
-
1x Clear CMOS jumper
-
1x TPM module connector
-
1x Serial port connector
-
1x Tuning Controller Connector
-
- Back Panel Ports:
-
Keyboard / Mouse
-
VGA
-
DisplayPort
-
USB 3.2 Gen 2 10Gbps Type-A
-
LAN port
-
WiFi / Bluetooth
-
Audio connector
-
USB 2.0
-
HDMI
-
USB 3.2 Gen 1 5Gbps Type-A
-
-
LED Features:
-
1x 4-pin RGB LED connector
-
1x 3-pin RAINBOW LED connector
-
4x EZ Debug LED
-
- Dimensions:
-
Micro-ATX Form Factor
-
9.6 in. x 9.6 in. (24.4 cm x 24.4 cm)
-
-
Operating System: Support for Windows 10 64-bit
