80 PLUS ORO CERTIFICADO
VENTILADOR LDB DE 120 MM
CIRCUITOS AVANZADOS
CABLES PLANOS Y FLEXIBLES

MODEL MPY-7501-ACAAG

ATX VERSIONATX 12V V2.31

PFCActive PFC (>0.95 typical)

INPUT VOLTAGE100-240V

INPUT CURRENT12-6A

INPUT FREQUENCY 50/60Hz

DIMENSIONS (L X W X H)140 x 150 x 86 mm

FAN SIZE120mm

FAN BEARING LDB

POWER GOOD SIGNAL100 – 500 ms

HOLD UP TIME>14ms at 100% load

EFFICIENCY90% Typically

ERP 2013 LOT 6Yes

MTBF>100,000 Hours

OPERATING TEMPERATURE 0-45°C

PROTECTIONS OPP, OVP, UVP, SCP, OTP, OCP

REGULATORY CCC, CE, TUV-SUD, RCM, EAC, cTUVus, FCC, BSMI, CB

MB 24-PIN CONNECTORS 1

CPU 12V 4+4 PIN CONNECTORS 1

CPU 12V 8 PIN CONNECTORS 1 (for updated models)

SATA CONNECTORS 8

PERIPHERAL 4-PIN CONNECTORS 6

FDD CABLE 4-PIN CONNECTORS 1

PCI-E 6+2 PIN CONNECTORS 4

80 PLUS Gold

MODULAR Non Modular

WATTAGE 500 to 750W

SERIESMWE Gold Series
